Stainless Steel CIP Pumps
Stainless steel self-priming pumps for cleaning-in-place duties and suitable process applications, selected to match your system.
Technical specifications
| Pump type | Liquid-ring self-priming pump |
|---|---|
| Stainless steel options | 304 or 316L, depending on configuration |
| Maximum flow | Up to 40 m³/h |
| Maximum head | Up to 42 m |
| Maximum suction lift | Up to 8 m under suitable conditions |
| Temperature range | −20 to 130 °C, depending on selection |
| Motor power range | 1.5–15 kW |
| Surface finish options | Ra ≤0.8, ≤0.6 or ≤0.4 µm |
| Mechanical seals | Single or double mechanical seal |
| Connections | Threaded, clamp, flanged or aseptic flanged |
Figures describe available range limits, not one pump operating at all maxima simultaneously. Confirm the selected size, duty point, motor, seals and materials with Tony before ordering.
Features and selection
- Self-priming pump range with alternative pump-head configurations.
- Single or double mechanical seal configurations; double seals are recommended in the supplied manual.
- Used in food, pharmaceutical, daily chemical and CIP applications, subject to material and duty compatibility.
- Motor, connections and seal configuration selected for the installation.
Self-priming does not mean dry-running. Fill the pump chamber before starting and follow the supplied installation and operating instructions. Confirm cleaning conditions and seal requirements with Tony.
Let us select the right pump
Send Tony the product being pumped, required flow rate, discharge pressure or head, temperature, viscosity, connection sizes and available power supply. Please mention any solids and cleaning requirements.
